700 x 700 mm Hole backlight (3FLH series) (LS-3FLH700700K70)
Model LS-3FLH700700K70
Hole backlight (3FLH) with SMD LEDs, luminous sizes 150 x 150 up to 1000 x 1000 mm; SM3, 4-pin WS16 or 4-pin WS20 aviation interface depending on size.
Features
- Backlight with a centre hole (K suffix in the model; drawing of LS-2FLH150150K40 shows a dia. 40 hole)
- Three-colour RGB light source, size and height, wavelength/colour temperature, mounting and input wire length customization
- Interface: SM3 (1.3 pin) up to 400 x 300; 4-pin WS16 aviation interface 400 x 400 to 600 x 400; 4-pin WS20 aviation interface 600 x 600 to 1000 x 1000
Specifications
| Model | LS-3FLH700700K70 |
|---|---|
| Voltage | 24 V DC |
| LED type | SMD |
| Wire length | 500 mm (drawing) |
| Operating environment (indoor) | temperature 0~40 °C, humidity 20~85% (non condensing) |
| Working life | white: 30000 hours, red: 30000 hours (the value varies according to the use environment) |
| Power tolerance | actual product power within ±10% of the table is the normal range |
| Quality service | one year product warranty, technical support |
| Luminous size (mm) | 700x700 |
| Voltage (V) | 24 |
| Power red (W) | 204.9 |
| Power blue/white (W) | 243.0 |
| Long (mm) | 714 |
| Wide (mm) | 754 |
| High (mm) | 32 |
| Remarks | 4-pin WS20 aviation interface |
| Shipping weight | 12.00 kg |
Applications
- Measurement of the four dimensions of the object
- Edge breakage detection
- Transparent object impurity detection
- Phone case edge detection
- Sole contour detection
Complete the station
Drive the light from a light controller and pair it with a lens for your field of view and working distance.
Light controllers LensesSelection guideOther sizes in the Hole backlight (3FLH series) series
| Model | Size | Power | Colours | Price | Availability | |
|---|---|---|---|---|---|---|
| LS-3FLH200100K50 | 200 x 100 mm | 13 W | $149.00 | 10 in stock | View | |
| LS-3FLH150150K50 | 150 x 150 mm | 19.3 W | $159.00 | 9 in stock | View | |
| LS-3FLH200200K50 | 200 x 200 mm | 28.3 W | $219.00 | 9 in stock | View | |
| LS-3FLH300200K50 | 300 x 200 mm | 43.7 W | $289.00 | 8 in stock | View | |
| LS-3FLH250250K50 | 250 x 250 mm | 45.6 W | $299.00 | 11 in stock | View | |
| LS-3FLH400200K50 | 400 x 200 mm | 50.2 W | $359.00 | 10 in stock | View | |
| LS-3FLH300300K50 | 300 x 300 mm | 56.7 W | $399.00 | 11 in stock | View | |
| LS-3FLH400300K50 | 400 x 300 mm | 76.3 W | $509.00 | 10 in stock | View | |
| LS-3FLH350350K50 | 350 x 350 mm | 77.9 W | $519.00 | 7 in stock | View | |
| LS-3FLH500300K50 | 500 x 300 mm | 73.9 W | $609.00 | 12 in stock | View | |
| LS-3FLH400400K50 | 400 x 400 mm | 102.4 W | $649.00 | 7 in stock | View | |
| LS-3FLH500400K50 | 500 x 400 mm | 99 W | $789.00 | 14 in stock | View | |
| LS-3FLH450450K50 | 450 x 450 mm | 100.2 W | $799.00 | 9 in stock | View | |
| LS-3FLH600400K50 | 600 x 400 mm | 119 W | $939.00 | 13 in stock | View | |
| LS-3FLH500500K50 | 500 x 500 mm | 124 W | $969.00 | 12 in stock | View | |
| LS-3FLH700500K70 | 700 x 500 mm | 172.9 W | $1,329.00 | 9 in stock | View | |
| LS-3FLH600600K50 | 600 x 600 mm | 179.2 W | $1,359.00 | 8 in stock | View | |
| LS-3FLH800600K70 | 800 x 600 mm | 238 W | $1,789.00 | 11 in stock | View | |
| LS-3FLH800800K70 | 800 x 800 mm | 256 W | $2,359.00 | 9 in stock | View | |
| LS-3FLH900900K70 | 900 x 900 mm | 324.6 W | $2,969.00 | 12 in stock | View | |
| LS-3FLH10001000K70 | 1000 x 1000 mm | 401.2 W | $3,649.00 | 9 in stock | View |
