6 mm Second generation spot light (2SL) (LS-2SL083)
Model LS-2SL083
High-power LED spot light with a simplified optical design giving higher luminance than the SL series, in a more compact body.
Features
- High power LED, high luminance
- Simplified optical design, higher luminance than SL series
- Optimized physical design, more compact
Specifications
| Model | LS-2SL083 |
|---|---|
| Power | 3 W |
| Adapted controller | Constant current controller |
| Customizable | multi-area control, colour and colour temperature, cable length, installation method, power |
| Cable (mm) | 500 (drawing) |
| Operating temperature | 0-50 °C |
| Operating humidity | 20-85% (non-condensing) |
| Life span | 50000 h (to 50% of factory-default luminance) |
| Extension cable options | PVC extension cable (high flexibility, bending and heat resistant, for use inside equipment) or high-flexibility extension cable (harder and more abrasion resistant than PVC, for drag-chain production lines) |
| Custom wavelengths | UV & IR light can be customized as required |
| Power (W) | 3 |
| Weight (g) | 37 |
| Body dia. (mm) | 24 |
| Length (mm) | 62 |
| Emitting port dia. (mm) | 6 |
| Mounting | M3 depth 7, 2-M3 depth 2 |
| Dimension drawing | 1 |
| Common | Y |
Applications
- Mark position location
- ITO glass circuit inspection
- Oral liquid impurity inspection
- Liquid crystal glass base counterpoint
- Imaging example: transparent glass concealed circuit inspection (LS-2SL083-W)
Complete the station
Drive the light from a light controller and pair it with a lens for your field of view and working distance.
