Hole backlight (2FLH series) (LS-2FLH200150K50)
Model LS-2FLH200150K50
Backlight with a centre hole so the camera or a coaxial light can look through it; luminous sizes 150 x 150 to 400 x 400 mm, SMD LEDs.
Features
- Backlight with a centre hole (K suffix in the model; drawing of LS-2FLH150150K40 shows a dia. 40 hole)
- Three-colour RGB light source, size and height, wavelength/colour temperature, mounting and input wire length customization
- Luminous size: 150mm*150mm. Hole diameter: 40mm.
- Brightness level 255, connected to the controller can be adjusted.
- Life span:30000 hours for red light and 30000 hours for white light.
- Suitable for large area inspection such as large volume object measurement, robotic arm grasping illumination, contour detection and transparent object impurity detection.
Specifications
| Model | LS-2FLH200150K50 |
|---|---|
| Voltage | 24 V DC |
| LED type | SMD |
| Wire length | 500 mm (drawing) |
| Operating environment (indoor) | temperature 0~40 °C, humidity 20~85% (non condensing) |
| Working life | white: 30000 hours, red: 30000 hours (the value varies according to the use environment) |
| Power tolerance | actual product power within ±10% of the table is the normal range |
| Quality service | one year product warranty, technical support |
| Category | Hole backlight |
| Color | red/white/blue/green |
| Wavelength | red: 620-635nm; white: —; blue: 465-470nm; green: 525-530nm |
| Color-temperature | red: —; white: 6000-6500K; blue: —; green: — |
| Power | red: —; white: 20Wmax.; blue: 20Wmax.; green: 20Wmax. |
| Input Volt | DC24Vmax. |
| Cable length | 0.6m |
| Terminal Plug | Flat head 3PIN2 pin |
| Connector Definition | 1:positive(+)red; 2:leave empty; 3:negative(-)black. |
| Shell Material | Aluminum Alloy (Oxidative blackened surface) |
| Cooling | Naturalair cooling |
| Dimensions | L214mm*W164mm*H21mm |
| Shell Hardness Parameters | Static load 230N±10N,time 5 minutes contact area:diameter 30MM Energy level:5J elements: steel ball diameter 50MM,500g±25g |
| ElectricalIn Sulation Capacity | DC500V Insulation resistance>20 megohms |
| Pressure Resistance Requirements | AC1000 V10mA/5S |
| Flammability Rating | IEC60707 |
| Operating Temperatureand Humidity | Temperature:0 to 50ºC,Humidity:20% to 85%RH(non-condensing) |
| Lifespan | Under our specified conditions of use,30000 hours for red light and 30000 hours for white light,the brightness is reduced to 50% of the factory value |
| Warranty Period | Under the conditions of use specified by the company,the warranty is two years from the date of shipment,and within two years,if there is a failure problem,it can be repaired or replaced free of charge |
| Value Added Services | One year free technical support |
| Brightness Controller (optional) | 1.Analog Controller 2.Digital Controller |
| Matingcable (optional) | 1.Light source extension cable 2.Connector adapter cable |
| Shipping weight | 1.00 kg |
