Machine vision lenses
F mount 29 MP full frame lens, 28 mm, M58 / F-mount (LS-2828M)
Model LS-2828M
Full frame F-mount lenses for 29 million pixel cameras: compact design, image sensor coverage dia. 43.2mm, adjustable flange distance, supports 5.5um pixels.
Features
- Compact design
- Full frame design, image sensor cover dia. 43.2mm
- Adjustable flange distance, F mount, thread design
- Support 5.5um pixel, 29 million high resolution line scan camera
Specifications
| Model | LS-2828M |
|---|---|
| Mount | M58, F |
| Max. supporting target surface | dia. 44 mm |
| Image space resolution | 5 um |
| Resolution | 29 MP |
| Focal length (mm) | 28 |
| Magnification range (X) | 0.03-0.08 |
| Aperture F/# | 2.8-22 |
| Distortion (%) | <3.2 |
| WD (mm) | 350.2-967.5 |
| Max. supporting target surface (mm) | dia. 44 |
| Image space resolution (um) | 5 |
| Sensor format | dia. 44 mm (full frame) |
| Working distance (mm) | 350.2-967.5 |
| Shipping weight | 0.38 kg |
Applications
- Cellphone screen inspection
- LCD screen inspection
- Glass cover-plate inspection
- Printing inspection
- Photovoltaic inspection
- OLED
