Machine vision lenses
1.1 inch macro 12 MP industrial lens, 25 mm, 1.1", C-mount (LS-2535A-12MP)
Model LS-2535A-12MP
1.1 inch macro (microspur) 12 million pixel industrial lenses: short working distance, ultra low distortion (< 0.03%), dia. 18.4mm image, magnification 0.05 to 0.82 optional; can replace a telecentric lens.
Features
- Short working distance
- Anti-knock function
- Ultra low distortion < 0.03%
- dia. 18.4mm image
- Magnification from 0.05 to 0.82 optional
- Supports 12 million high resolution cameras
- Replaces telecentric lens
Specifications
| Model | LS-2535A-12MP |
|---|---|
| Format | 1.1" |
| Mount | C |
| Relative illuminance | >90% |
| Image space resolution | 3.5 um |
| Resolution | 12 MP |
| Focal length (mm) | 25 |
| Magnification range (X) | 0.1-0.4 |
| Aperture F/# | 1:3.5 |
| Distortion (%) | <0.05 |
| Relative illuminance (%) | >90 |
| WD (mm) | 142 |
| Conjugate distance (mm) | 182.9 |
| Image space resolution (um) | 3.5 |
| Supporting image sensor | 1.1" |
| Sensor format | 1.1" |
| Working distance (mm) | 142.0 |
| Shipping weight | 0.38 kg |
Applications
- AOI, SPI
- Semiconductor
- Fastener inspection
- SMT
- 3C
- Food and drug
Complete the station
Drive the light from a light controller and pair it with a lens for your field of view and working distance.
Light controllers LensesSelection guideOther sizes in the 1.1 inch macro 12 MP industrial lens series
| Model | Size | Price | Availability | |
|---|---|---|---|---|
| LS-3530A-12MP | 35 mm, 1.1", C-mount | $219.00 | 5 in stock | View |
| LS-5028A-12MP | 50 mm, 1.1", C-mount | $239.00 | 2 in stock | View |
| LS-7528A-12MP | 75 mm, 1.1", C-mount | $259.00 | 2 in stock | View |
