Representative photo of this series
Light controllers
ABS analog controller, 4 ch, 120 W (LS-120-MA01-24010-4)
Model LS-120-MA01-24010-4
Controller section 'ABS analog controller' of the light controller selection manual (cards P19-P20).
Features
- Simulated constant voltage control
- Low trigger response time
- Supports external trigger mode
- Constant-on and constant-off modes can be switched
- Rotary knob for stepless linear adjustment of brightness
- 5~24V trigger, adaptable to high and low level trigger modes
- Small size, easy to install, screw mounting or C45 rail mounting
Specifications
| Model | LS-120-MA01-24010-4 |
|---|---|
| Output voltage | 24V |
| Number of channels | 4 |
| Built-in power supply | 120W |
| Connected light source type | 10mA~1A 24V power supply |
| Max input voltage | 220VAC |
| Max output voltage | 24V |
| Max current per channel | 1A |
| Overheat protection | No |
| Short circuit protection | No |
| Working mode | 0: normally off, 1: on |
| Brightness levels | Stepless |
| Millisecond strobe time | no |
| Microsecond strobe time | no |
| Communication baud rate | no |
| Trigger mode | Level trigger |
| Operating temperature | 5~50 C |
| Luminous mode | Normally on / normally off |
| Driving mode | Stepless analog constant voltage |
| Dimension | 90 x 106 x 150 mm |
| Manual page code | P20 |
| Mounting | Screw or C45 rail installation |
| Total output (W) | 120 |
| Control | Analog knob (stepless) |
| Shipping weight | 0.70 kg |
