Mobile robots
Hikrobot C3-400B4 Heavy-Load Mobile Robot
Model C3-400B4
Hikrobot C3-400B4 heavy-load mobile robot. Heavy Load, High Precision
Specifications
| Model | C3-400B4 |
|---|---|
| Brand | Hikrobot |
| Rated Load (kg) | 4*100 |
| Rated Speed (m/s) | 1.2 |
| Navigation | SLAM/QR code |
| Rated Acceleration (m/s²) | 0.5 |
| Rotation Diameter (mm) | 1415 |
| Obstacle Avoidance | 360° Laser/Auxiliary protection |
| Dimension L*W*H (mm) | 1250*745*1175 |
| Transferred Method | Rollers |
| Weight (kg) | 410 |
| Angular Accuracy (°) | ±1 |
| Positioning Accuracy (mm) | ±10 |
| Run time (h) | 8 |
| Shipping | Freight, quoted with the order |
