Hikrobot MV-IDH7000B/10ER/12RN/LS Rugged long-range wireless handheld code reader Fast Ethernet kit
Model MV-IDH7000B/10ER/12RN/LSHikrobot
- Resolution1280 × 800
- SensorCMOS
- ConnectionWireless
- Min. accuracy10 mil
Ships in 2-3 weeks
0.67 kg shipping weight
Not available in the United States. Available for delivery to other countries.
Ask an engineerBrowse Handheld code readers
lumaspecvision.com/products/lumaspec-mv-idh7000b-10er-12rn-ls
MV-IDH7000B/10ER/12RN/LS is a handheld reader with a Fast Ethernet interface (red/white-light, LED indicator prompt): it sits on a plain 100 Mbit network. You also get a resolution of 1280 x 800 and a field of view of 18° (H) x 10° (V).
Hikrobot MV-IDH7000B/10ER/12RN/LS Rugged long-range wireless handheld code reader Ethernet kit.
Tracked shipping 3-year warranty Engineer support Net 30 for approved accounts Secure checkout Shipping, warranty, support and payment details
- Tracked worldwide shippingTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Final sale Hikrobot products cannot be returned or exchanged; a defective or wrong item is covered by the warranty. Return policy
CertificationsCEKC
Specifications
General
| Model | MV-IDH7000B/10ER/12RN/LS |
|---|---|
| Brand | Hikrobot |
| Min. accuracy | 10 mil |
| Detection angle | Tilt angle ± 60°, skew angle ± 60°, rotation angle 360° |
| Symbol contrast | 20 % |
| Battery | 3150 mAh |
| Charging time | Shutdown mode: 12 VDC (12 V, 2 A): 3.5 h |
| Endurance | 13 h (interval scanning, once in 2 seconds) |
| Prompt | LED indicator, buzzer, vibrator |
| Laser safety class | Laser 2 |
| Charging time (smart base) | 4 h |
Optics
| Depth of field | Code 39(10mil):540 mm ~1200 mm; Code 39(20 mil):* ~ 2100 mm; Code 39(50 mil):* ~ 3900 mm; Code 39(100 mil):* ~ 6400 mm; Code 128(10 mil):600 mm ~ 1000 mm; Code 128(20 mil):* ~ 2100 mm; Code 128(100 mil):* ~ 6400 mm; Data Matrix (50 mil):200 mm ~ 3600 mm; QR Code (20 mil):600 mm ~ 1500 mm; QR Code (33 mil)300 mm ~ 2400 mm; QR Code (100 mil):* ~ 6400 mm |
|---|---|
| Field of view | 18° (H) × 10° (V) |
Sensor and imaging
| Symbologies | 1D codes: Code 39, Code 93, Code 128, GS1-Code128, CodaBar, EAN 8, EAN 13, ISBN, ISSN, ITF 25, ITF 14, UPCA, UPCE; 2D matrix codes: QR Code, Data Matrix, MicroQR, Aztec, Han Xin; Stacked code: PDF417 |
|---|---|
| Sensor type | CMOS |
| Resolution | 1280 × 800 |
| Aiming system | Dot laser aiming |
Interfaces and I/O
| Communication mode | Bluetooth BT 5.0, BLE |
|---|---|
| Wireless range | 100 m (open range) |
| Client software | IDMVS |
| Communication protocol | SmartSDK, TCP Client, FTP, TCP Server, Profinet, EthernetIP, Modbus, UDP, Serial, Bluetooth, FINS, Melsec/SLMP |
| Data interface | Fast Ethernet (100 Mbit/s), RS-232, DC terminal |
Light
| Ambient illumination | 0 ~ 100000 lux |
|---|---|
| Light source | 2 light types supported: diffuse light (red), direct light (white) |
| Laser wavelength | 650 nm |
Environment and compliance
| Ingress protection | IP65 |
|---|---|
| Temperature | Working temperature: –10 °C to 50 °C (14 °F to 122 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F); Charging temperature: 0 °C to 40 °C (32 °F to 104 °F) |
| Humidity | 20% RH to 95% RH (no condensation) |
| Certification | CE, KC |
| Ingress protection (smart base) | IP40 |
| Humidity (smart base) | 20% RH to 95% RH (no condensation) |
| Temperature (smart base) | Working temperature: –10 °C to 50 °C (14 °F to 122 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F); Charging temperature: 0 °C to 40 °C (32 °F to 104 °F) |
Electrical
| Laser output power (max.) | 1 mW |
|---|---|
| Power supply | 12 VDC |
| Current consumption | 0.7 A (max.), 0.06 A (during standby) |
Mechanical
| Dimension | 73.4 mm × 104 mm × 215.2 mm |
|---|---|
| Weight | Approx. 410 g |
| Drop height | 2.0 m |
| Pulse width | 8 ms |
| Dimension (smart base) | 248.4 mm × 106.3 mm × 69.4 mm |
| Weight (smart base) | Approx. 380 g |
| Shipping weight (estimated) | 0.67 kg |
Downloads
Size
To scale, from the printed dimensionsFeatures
- The same series also comes with USB 2.0 + Fast Ethernet or USB 2.0
- CMOS sensor
- Weighs about 410 g
- In-house high-performance barcode algorithm with excellent DPM code reading
- Robust algorithm handles dirty, damaged and low-contrast codes
- Bluetooth 5.0 wireless with stable connections up to 100 m in open areas, free of cables; also connects to phones, tablets and other mobile devices for more efficient operation
- With the smart base, connects to IDMVS for parameter configuration and device management
- 3150 mAh battery for long runtime
- IP65 protection and repeated 2.0 m drops for harsh industrial environments
- Special high-density and long-range reading models for diverse industrial applications
Complete the station
Engineering data
The MV-IDH7000B/10ER/12RN/LS at a glance
Before you buy
Questions about the MV-IDH7000B/10ER/12RN/LS
Answered from this model's printed specifications and our fit tests. Calculated figures say “about”.
Which codes does the MV-IDH7000B/10ER/12RN/LS read?
The symbologies are 1D codes: Code 39, Code 93, Code 128, GS1-Code128, CodaBar, EAN 8, EAN 13, ISBN, ISSN, ITF 25, ITF 14, UPCA, UPCE; 2D matrix codes: QR Code, Data Matrix, MicroQR, Aztec, Han Xin; Stacked code: PDF417.
How far does the MV-IDH7000B/10ER/12RN/LS read?
The depth of field is Code 39(10mil):540 mm ~1200 mm; Code 39(20 mil):* ~ 2100 mm; Code 39(50 mil):* ~ 3900 mm; Code 39(100 mil):* ~ 6400 mm; Code 128(10 mil):600 mm ~ 1000 mm; Code 128(20 mil):* ~ 2100 mm; Code 128(100 mil):* ~ 6400 mm; Data Matrix (50 mil):200 mm ~ 3600 mm ...
How does the MV-IDH7000B/10ER/12RN/LS connect?
The communication mode is Bluetooth BT 5.0, BLE. The communication protocol is SmartSDK, TCP Client, FTP, TCP Server, Profinet, EthernetIP, Modbus, UDP, Serial, Bluetooth, FINS, Melsec/SLMP.
What power supply does the MV-IDH7000B/10ER/12RN/LS need?
It runs on 12 VDC. The current consumption is 0.7 A (max.), 0.06 A (during standby).
What is the MV-IDH7000B/10ER/12RN/LS's IP rating?
It is rated IP65.
Learn
Guides for this part
Engineering guides picked for the MV-IDH7000B/10ER/12RN/LS: how to choose it, set it up and get a better image.
Other models in the IDH7000 Series Handheld Code Reader series
See all 34 models in the seriesHow this model compares
- Compared with KM-DMH7B/10SR/07RN/LS: minimum accuracy 10 mil here, 3 mil there; field of view 18° (H) × 10° V here, 31° (H) × 20° V there.
Swipe to see all columns
| Model | Connection | Min. accuracy | Field of view | Dimension (smart base) | Price | Availability | Link |
|---|---|---|---|---|---|---|---|
| KM-DMH7B/10SR/07RN/LS | Wireless | 3 mil | 31° (H) × 20° (V) | $239.00 | Ships in 2-3 weeks | View | |
| MV-8650/10HHD/12RN/US | Wireless | 1.5 mil | 18° (H) × 10° (V) | 248.4 mm × 106.3 mm × 69.4 mm | $239.00 | Ships in 2-3 weeks | View |
| MV-IDH7000B/10SR/07RN/LS | Wireless | 3 mil | Horizontal 31°, vertical 20° | $479.00 | Ships in 2-3 weeks | View | |
| MV-IDH7000B/10NR/07RN/LS | Wireless | 3 mil | Horizontal 31°, vertical 20° | $479.00 | Ships in 2-3 weeks | View | |
| MV-IDH7000B/10HHD/07RN/LS | Wireless | 3 mil | Horizontal 31°, vertical 20° | $479.00 Quote | Ships in 2-3 weeks | View | |
| MV-IDH7000B/10ER/12RN/LSThis model | Wireless | 10 mil | 18° (H) × 10° (V) | 248.4 mm × 106.3 mm × 69.4 mm | $479.00 | Ships in 2-3 weeks | |
| MV-IDH7000P/10ER/12RN/L | Wired | 10 mil | 18° (H) × 10° (V) | $479.00 | Ships in 2-3 weeks | View | |
| MV-IDHBG013D/10NR/07RN/US | 3 mil | 31° (H) × 20° (V) | 248.4 mm × 106.3 mm × 69.4 mm | $719.00 | Ships in 2-3 weeks | View | |
| MV-IDH7050B/10SR/07RN/US | 3 mil | 31° (H) × 20° (V) | $719.00 | Ships in 2-3 weeks | View |
