Spot lights
Spot Light, 8 x 3 mm, Yellow (LS-SPT-0157)
Model LS-SPT-0157
- ColourYellow
- Size59 mm × Ø24 mm
- Power2 W
- Wavelength580 ~ 595 nm
$239.00
Ships in 2-3 weeks
0.2 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Spot Light, 8 x 3 mm, Yellow. The light outlet adopts efficient light-guiding design and highlight LED. Adopts compact size and high heat-dissipation structural design.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-SPT-0157 |
|---|---|
| Safety class | No danger |
| Cooling mode | Natural cooling |
Optics
| Best working distance | 65 ~ 200 mm |
|---|
Interfaces and I/O
| Connector type | SMR-03V-B |
|---|---|
| Cable length | 1 m |
Light
| Color | Yellow |
|---|---|
| Center illuminance/irradiance | > 20K lux@WD=100 mm |
| Wavelength | 580 ~ 595 nm |
Environment and compliance
| Temperature | Working temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F) |
|---|---|
| Humidity | 20% RH to 90% RH (no condensation) |
Electrical
| Power | 2 W |
|---|---|
| Input current | 680 mA |
| Drive mode | Constant current |
| Supply voltage (derived) | 24 V DC, derived: all 370 lights of this range with the same connector type that state a voltage are rated 24 V |
Mechanical
| Dimension | 59 mm × Ø24 mm |
|---|---|
| Optical outlet diameter | Ø8 mm |
| Weight | 75 g |
| Shipping weight (estimated) | 0.20 kg |
Other models in the Spot lights (LS-SPT-S41) series
See all 5 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-SPT-0156 | 8 x 3 mm, White | $239.00 | Ships in 2-3 weeks | View |
| LS-SPT-0155 | 8 x 3 mm, Red | $239.00 | Ships in 2-3 weeks | View |
| LS-SPT-0153 | 8 x 3 mm, Blue | $239.00 | Ships in 2-3 weeks | View |
| LS-SPT-0154 | 8 x 3 mm, Green | $239.00 | Ships in 2-3 weeks | View |
