Shadowless lights
120 x 60 mm tunnel shadowless light (LS-SDL-0173)
Model LS-SDL-0173
- ColourWhite
- Emitting area120 x 60 mm
- Voltage24 V
- Length120 mm
$440.00
Ships in 3-4 weeks
2.0 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Tunnel shadowless light for glare-free light on shiny parts. Emitting area 120 x 60 mm; available in white.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-SDL-0173 |
|---|---|
| Pin assignment | 1: (+), 2: NC, 3: (-) |
| Service life | White:30,000hrs (Depends on the operating environment, not a gurantee) |
Interfaces and I/O
| Connector | SMR-03 V-B |
|---|---|
| Cable length | 500 mm |
Light
| Emitting area (mm) | 120 x 60 |
|---|
Environment and compliance
| Operating environment | Temperature: 0~40 °C Humidity:20% to 85% RH (with no condensation) |
|---|
Electrical
| Supply voltage | 24 V |
|---|
Mechanical
| Length (mm) | 120 mm |
|---|---|
| Width (mm) | 60 mm |
| Outer diameter (mm) | 140 mm |
| Inner diameter (mm) | 108 mm |
| Height (mm) | 87.3 mm |
| Housing material | Aluminum alloy, Resin |
| Shipping weight | 2.00 kg |
Other models in the Tunnel shadowless lights (LS-SDL-S31) series
See the category| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-SDL-0174 | 1060 x 118 mm | $1,030.00 | Ships in 3-4 weeks | View |
