Representative photo of this series
Shadowless lights
Square shadowless light, 140 x 110 x 80 mm (LS-SDL-0033)
Model LS-SDL-0033
- ColourRed, Green, Blue, White
- Emitting area112 x 56 mm
- SizeL140xW110xH80(mm)
- Voltage24V
- Power10.8W/13.7W
$539.00
In stock - ships the same business day (4 available, order by 2 PM ET)
0.9 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
High uniformity, high luminance. Large emitting area, wide range of applications. Can be used in large FOV with multiple cameras.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-SDL-0033 |
|---|---|
| Note | UV & IR light can be customized as required. |
| Viewport (camera hole) | 68 mm |
Interfaces and I/O
| Cable polarity | 1: +, 2: NC, 3: - |
|---|---|
| Cable (mm) | 500 (drawing) |
Light
| LED colour | R(red)/W(white) |
|---|---|
| Emitting surface (mm) | 112 x 56 |
Electrical
| Voltage | 24V |
|---|---|
| Power | 10.8W/13.7W |
| Input voltage | DC 24V (max) |
Mechanical
| Dimension | L140xW110xH80(mm) |
|---|---|
| Shipping weight | 0.90 kg |
Other models in the Square shadowless light (LS-SDL-S06) series
See the category| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-SDL-0032 | Red, Green, Blue, White · 100 x 90 mm | $559.00 | 16 in stock | View |
