Representative photo of this series
360° inspection lenses
360° imaging system (inner surface), 1/3", C-Mount (LS-PCL-0077)
Model LS-PCL-0077
- MountC-mount
- Sensor1/3"
- Working distance12.5-50 mm
- ApertureF14
$909.00
Ships in 2-3 weeks
0.94 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Inner-surface inspection lens with integrated LED light source that highlights tiny defects from a super wide angle of view and clearly detects hidden internal features; for objects whose internal features can only be inspected through the inner surface, such as engine parts, containers and pipes; super large depth of field; measuring objects of min. 5 mm diameter.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-PCL-0077 |
|---|---|
| F/NO | 14 |
Optics
| Image size (dia.) | dia. 3.6 |
|---|---|
| Working distance | 12.5-50 |
| Aperture | F14 |
Sensor and imaging
| Sensor | 1/3" |
|---|---|
| Sensor format | 1/3" |
Light
| Illumination | Embedded illumination |
|---|
Mechanical
| Mount | C-Mount |
|---|---|
| Shipping weight | 0.94 kg |
Other models in the 360° imaging system (inner surface) (LS-PCL-S15) series
See the category| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-PCL-0078 | 2/3", C-Mount | $909.00 | Ships in 2-3 weeks | View |
