Line scan lenses
80 mm, 0.1x Line Scan Lens (LS-LSL-0236)
Model LS-LSL-0236
- Focal length80 mm
- Magnification0.05-0.25x
- MountM42
- SensorLarge format
- Working distance357-1600 mm
$2,179.00
In stock - ships the same business day (5 available, order by 2 PM ET)
0.94 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
80 mm, 0.1x Line Scan Lens. Line scan lens selection table: focal length, maximum image circle, center magnification / working distance, FOV per camera type and mount options. At a glance: center magnification 0.1x; center working distance 820 mm; focal length 80 mm; sensor class 8K 7 um; mount options M42, M58, M72.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-LSL-0236 |
|---|---|
| Center conjugate distance (I.O) | 927 mm |
| FOV with 16k 3.5 um camera | 224-1120 mm |
| FOV with 8k 7 um camera | 224-1120 mm |
| FOV with 8k 5 um camera | 160-800 mm |
| FOV with 4k 7 um camera | 112-560 mm |
| FOV with 4k 5 um camera | 80-400 mm |
| Conjugate distance range (I.O) | 476-1703 mm |
| Conjugate distance range (WD/Mag data) | 475.6-1705.1 mm |
Optics
| Focal length | 80 mm |
|---|---|
| Max image circle | dia. 62 mm |
| Center magnification | 0.1x |
| Center working distance | 820 mm |
| Magnification range | 0.05-0.25x |
| Working distance range | 357-1600 mm |
| Magnification range (WD/Mag data) | 0.05-0.2495x |
| Working distance range (WD/Mag data) | 357-1602 mm |
Sensor and imaging
| Sensor class | 8K 7 um |
|---|
Mechanical
| Mount options | M42, M58, M72 |
|---|---|
| Shipping weight (estimated) | 0.94 kg |
Photo shows a representative model of this series; see the specifications for this model.
