Machine vision lenses

18 mm liquid lens, F6.0, C-mount (LS-FFL-1663)

Model LS-FFL-1663

Focal length18 mm
MountC-mount
Sensor1.1"
Working distance0.1-2 m
ApertureF6.0
Field of view50.66° ×41.8° ×31.2°

$990.00

Ships in 3-4 weeks

0.5 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

18 mm liquid lens for machine-vision cameras. Focal length 18 mm; working distance 0.1-2 m; aperture F6.0; C-mount.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	LS-FFL-1663
Angle of view	50.66° ×41.8° ×31.2°

Optics

Focal length	18 mm
Aperture	F6.0
Working distance	0.1-2 m
Field of view	50.66° ×41.8° ×31.2°
Distortion	<0.5%

Sensor and imaging

Sensor format	18 mm

Interfaces and I/O

Electrical Interface	Aviation Socket

Mechanical

Mount	C
Flange back length	17.526 mm
Shipping weight	0.50 kg
