Representative photo of this series
Machine vision lenses
2/3" 5-10 megapixel ultra-high resolution FA lens, 12 mm, C-mount (LS-FFL-1656)
Model LS-FFL-1656
- Focal length12mm
- MountC-mount
- Sensor2/3"
- ApertureF1.6
- Resolution5-10
$179.00
Ships in 2-3 weeks
0.38 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
2/3" 5-10 megapixel ultra-high resolution lens.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-FFL-1656 |
|---|---|
| Fastening mode | Manual |
Optics
| Focal length | 12mm |
|---|---|
| Iris (F) | 1.6 |
| Filter screw size | M35.5*P0.5 |
| Aperture | F1.6 |
Sensor and imaging
| Sensor size | 2/3" |
|---|---|
| Sensor format | 2/3" |
| Resolution (MP) | 5-10 |
Environment and compliance
| Service temperature | -20°C~+60°C |
|---|
Mechanical
| Mount | C |
|---|---|
| Shipping weight | 0.38 kg |
Other models in the 2/3" 5-10 megapixel ultra-high resolution FA lens (LS-FFL-S160) series
See all 6 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-FFL-1655 | 8 mm, 2/3", C-mount | $169.00 | Ships in 2-3 weeks | View |
| LS-FFL-1658 | 25 mm, 2/3", C-mount | $199.00 | Ships in 2-3 weeks | View |
| LS-FFL-1657 | 16 mm, 2/3", C-mount | $209.00 | Ships in 2-3 weeks | View |
| LS-FFL-1659 | 35 mm, 2/3", C-mount | $219.00 | Ships in 2-3 weeks | View |
| LS-FFL-1660 | 50 mm, 2/3", C-mount | $249.00 | Ships in 2-3 weeks | View |
