Representative photo of this series
Machine vision lenses
Fixed lens for FA, 4/3" 20MP, 50 mm, C-Mount (LS-FFL-0717)
Model LS-FFL-0717
- Focal length50 mm
- MountC-mount
- Sensor4/3"
- ApertureF2.8-22
- Resolution20MP
- Field of view19.8° x 14.9°
$739.00
Ships in 2-3 weeks
0.38 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Industrial FA lenses supporting 4/3" sensors and compatible with 1.1" and 2/3" sensors, for 20MP area array cameras, with high relative illuminance, large aperture, compact structure and high contrast.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-FFL-0717 |
|---|---|
| F/NO | 2.8-22 |
| EFL | 50mm |
| MOD | 0.3m |
Optics
| Distortion | <0.1% |
|---|---|
| Image size | 4/3" |
| Image size (dia.) | 4/3" |
| Field of view angle 4/3" | 19.8° x 14.9° |
| Field of view angle 1" | 14.6° x 10.9° |
| Field of view angle 2/3" | 10.1° x 7.5° |
| Distortion (TV) 4/3" | <0.1% |
| Focal length (mm) | 50 |
| Aperture | F2.8-22 |
Sensor and imaging
| Resolution | 20MP |
|---|---|
| Sensor format | 4/3" |
Mechanical
| Mount | C-Mount |
|---|---|
| Filter size | M35.5×P0.5 |
| Shipping weight | 0.38 kg |
Other models in the Fixed lens for FA, 4/3" 20MP (LS-FFL-S94) series
See all 5 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-FFL-0713 | 12 mm, 4/3", C-Mount | $669.00 | Ships in 2-3 weeks | View |
| LS-FFL-0714 | 16 mm, 4/3", C-Mount | $679.00 | Ships in 2-3 weeks | View |
| LS-FFL-0715 | 25 mm, 4/3", C-Mount | $689.00 | Ships in 2-3 weeks | View |
| LS-FFL-0716 | 35 mm, 4/3", C-Mount | $709.00 | Ships in 2-3 weeks | View |
