Representative photo of this series

Machine vision lenses

Industrial lens, 2/3" 10MP FA lens, 16 mm, C-mount (LS-FFL-0494)

Model LS-FFL-0494

Focal length16 mm
MountC-mount
Sensor2/3"
Aperture2.8
Resolution10
Field of view113.6 x 85.2

$319.00

Ships in 2-3 weeks

0.38 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Industrial lens, 2/3" 10MP FA lens with mount C Mount, max image surface size 2/3", focal length 16, aperture 2.8, fov @ wd 200 113.6 x 85.2.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	LS-FFL-0494
Min distance	0.1M

Optics

Focal length (mm)	16
Aperture	2.8
TV distortion	<0.1%
Filter thread	M27 x P0.5
Field of view	113.6 x 85.2

Sensor and imaging

FOV @ WD 200 (H x V), 2/3" sensor	113.6 x 85.2
FOV @ WD 200 (H x V), 1/2" sensor	83.1 x 62.3
FOV @ WD 200 (H x V), 1/3" sensor	61.5 x 46.1
Sensor format	2/3"
Resolution (MP)	10

Interfaces and I/O

Interface	C Mount

Mechanical

Mount	C Mount
Max image surface size	2/3"
Shipping weight	0.38 kg

Other models in the Industrial lens, 2/3" 10MP FA lens (LS-FFL-S80) series

See all 6 models

Model	Size / key data	Price	Availability	Link
LS-FFL-0492	8 mm, 2/3", C-mount	$309.00	Ships in 2-3 weeks	View
LS-FFL-0493	12 mm, 2/3", C-mount	$309.00	Ships in 2-3 weeks	View
LS-FFL-0497	50 mm, 2/3", C-mount	$389.00	Ships in 2-3 weeks	View
LS-FFL-0496	35 mm, 2/3", C-mount	$449.00	Ships in 2-3 weeks	View
LS-FFL-0495	25 mm, 2/3", C-mount	$489.00	Ships in 2-3 weeks	View
