Light controllers
DC65 digital controller, 4 ch, 65 W (LS-CTL-0220)
Model LS-CTL-0220
- Channels4
- Output5V
- InputAC220V (built-in switch power supply)
- Total output65 W
- Controlkeys / RS232 / Ethernet
$459.00
Ships in 2-3 weeks
0.5 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
4-channel digital light controller with built-in 65W 5V switching power supply for 5V point light sources, RS232 and 100-megabit Ethernet communication, constant-on / strobe modes with millisecond and microsecond strobe.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-CTL-0220 |
|---|---|
| Work modes | Five: NORMAL 0 = normal bright, 1 = normally off, 2 = constant bright; STROBE 0 = 1~999 ms strobe, 1 = 10~999 us strobe |
| Luminescence mode | Normal bright / constant off / constant bright / strobe (all except constant bright can be trigger controlled) |
| Panel | 4-digit display, MENU/+/- keys, LOCK/UNLOCK switch, NORMAL/STROBE switch, run and error indicators, T1-T4 trigger terminals, RS232 DB9 female, Ethernet, AC220V inlet |
| Control | keys / RS232 / Ethernet |
Interfaces and I/O
| Communication mode | Serial port (9600 baud, no parity, 8 data bits, 1 stop bit) / 100M Ethernet (default IP 192.168.1.200, TCP server, port 8800) |
|---|---|
| Light connector | pin 1 light +, pin 2 light |
Light
| Brightness levels | 255 |
|---|---|
| Light source type | 5V point light source (10mA~0.8A) |
Environment and compliance
| Operating ambient temperature | -5~50℃ |
|---|
Electrical
| Built-in power supply | 65W |
|---|---|
| Single-channel maximum current | 0.5A |
| Input voltage | AC220V (built-in switch power supply) |
| Output voltage | 5V |
| Output | 0.5A (single channel maximum current 0.8A, factory limit according to demand) |
| Trigger way | Edge + level trigger (edge in strobe mode, level in normal modes) |
| Millisecond strobe time | 1~999 ms |
| Microsecond strobe time | 10~999 us |
| Number of channels | 4 |
| Trigger response | ≤15us / ≤200us (two values in the timing tables) |
| Total output (W) | 65 |
Mechanical
| Size | See appendix (not included in the document) |
|---|---|
| Shipping weight | 0.50 kg |
