Representative photo of this series
Light controllers
Analog control box, 2 ch, 48 W (LS-CTL-0144)
Model LS-CTL-0144
- Channels2 Way
- Output12-24V
- InputDC 24V
- Total output48W
$189.00
In stock - ships the same business day (4 available, order by 2 PM ET)
0.5 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Analog control box with DC 24V input: 12-24V output voltage adjustable, manual luminance control, buckle (DIN) rail installation and self-recovering short-circuit protection.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-CTL-0144 |
|---|---|
| Normal on/normal closed mode switch | supported (toggle switch TS) |
| Constant on / off switch | Support |
| Product | Analog controller box |
Light
| Luminance control method | manual adjusting |
|---|---|
| Luminance control mode | constant voltage |
| Luminance adjustment level | Stepless (knob adjustment) |
| Luminance adjustment method | Manual adjustment |
| Luminance adjustment mode | Constant current mode |
Electrical
| Input voltage | DC 24V |
|---|---|
| Output voltage range | 12-24V |
| External trigger voltage | 0-1.5V |
| Number of channels | 2 Way |
| Output voltage | 24V |
| Total output power | 48W |
| One way max. output power | 24W |
Mechanical
| Shipping weight | 0.50 kg |
|---|
Other models in the Analog control box (LS-CTL-S26) series
See all 4 models| Model | Size / key data | Price | Availability | Link |
|---|---|---|---|---|
| LS-CTL-0145 | 2 ch, 48 W | $189.00 | 3 in stock | View |
| LS-CTL-0146 | 2 ch, 60 W | $199.00 | 3 in stock | View |
| LS-CTL-0147 | 1 ch, 200 W | $239.00 | 4 in stock | View |
