Representative photo of this series

Light controllers

Brighten strobe controller, 2 ch, 200 W (LS-CTL-0081)

Model LS-CTL-0081

Channels2
Output48V
InputAC 100-240V
Total output200W
ControlRS232 serial port

$1,089.00

Ships in 2-3 weeks

1.1 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Brighten strobe controller: gives 48V to the light in an instant, luminous time adjustable 0-999us; in normal on mode luminance 0-100% adjustable; manual or RS232 control.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	LS-CTL-0081
Working mode	Normal on mode (internal self-trigger mode / external trigger mode)
Lighting time	0-999us
Lighting time delay	<2us

Interfaces and I/O

Communication	RS232 serial port

Light

Luminance control method	manual adjust by button, PC remote adjustment
Luminance control mode	brighten

Electrical

Input voltage	AC 100-240V
Input frequency	50/60Hz
Output voltage	48V
Baud rate	9600bps
Trigger signal	rising / falling edge trigger
External trigger signal effective frequency	<704Hz (cycle > 1.42ms)
Channels	2
One way max. output power	100W
Total output power	200W
External trigger support	Y
External trigger voltage	5-24V rising or falling edge

Mechanical

Shipping weight	1.10 kg

Other models in the Brighten strobe controller (LS-CTL-S11) series

See all 3 models

Model	Size / key data	Price	Availability	Link
LS-CTL-0080	2 ch, 60 W	$689.00	Ships in 2-3 weeks	View
LS-CTL-0082	4 ch, 200 W	$1,089.00	Ships in 2-3 weeks	View
